H07RN-F 10 3 - 10 Gauge Harmonized Cable
Our H07RN-F 10 3 10 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 10 3 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
H07RN-F 10 3
Part Number
H07RN-F 10 3
Attributes
No. of Cond.
3
Approx LBS/MFT
333.00
AWG Size
10
Cond. Material
Bare Copper
Conductor Stranding
78/28
Insul. Material
Synthetic Rubber
Jacket Material
Synthetic Rubber
Max. Temp
60C
Min. Temp
-25C
No. of Strands
78
Nom. O.D. of Cable (in)
0.575
Strand Size
28
Voltage
750
