H07RN-F 12 5 - 12 Gauge Harmonized Cable
Our H07RN-F 12 5 12 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 12 5 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
H07RN-F 12 5
Part Number
H07RN-F 12 5
Attributes
No. of Cond.
5
Approx LBS/MFT
316.00
AWG Size
12
Cond. Material
Bare Copper
Conductor Stranding
52/28
Insul. Material
Synthetic Rubber
Jacket Material
Synthetic Rubber
Max. Temp
60C
Min. Temp
-25C
No. of Strands
52
Nom. O.D. of Cable (in)
0.654
Strand Size
28
Voltage
750
