H07RN-F 14 5 - 14 Gauge Harmonized Cable
Our H07RN-F 14 5 14 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 14 5 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
H07RN-F 14 5
Part Number
H07RN-F 14 5
Attributes
No. of Cond.
5
Approx LBS/MFT
228.00
AWG Size
14
Cond. Material
Bare Copper
Conductor Stranding
46/30
Insul. Material
Synthetic Rubber
Jacket Material
Synthetic Rubber
Max. Temp
60C
Min. Temp
-25C
No. of Strands
46
Nom. O.D. of Cable (in)
0.563
Strand Size
30
Voltage
750
