H07RN-F 18 2 - 18 Gauge Harmonized Cable
Our H07RN-F 18 2 18 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 18 2 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
H07RN-F 18 2
Part Number
H07RN-F 18 2
Attributes
Approx LBS/MFT
0.00
AWG Size
18
Cond. Material
Bare Copper
Conductor Stranding
30/32
Insul. Material
Synthetic Rubber
Max. Temp
60C
Min. Temp
-25C
No. of Strands
30
Strand Size
32
Voltage
750
