SJEOOW

Our SJEOOW cord is a junior service portable cord suitable for use in both indoor and outdoor industrial environments. This portable cord features a TPE jacket that offers a wider continuous temperature range than rubber. TPE also provides better flexibility at very low temperatures. This cable has a 300V voltage rating and has a temperature range of –50ºC to 105ºC. These characteristics make it an excellent choice for mitigating outdoor factors that would otherwise alter the performance of wire or cable.

16 items

sjeoow 14/4
SJEOOW 14/4
Amps15
Approx LBS/MFT98
AWG Size14
Cond. MaterialBare Copper
Conductor Stranding41/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote per FT
sjeoow 12/2
SJEOOW 12/2
Amps25
Approx LBS/MFT90
AWG Size12
Cond. MaterialBare Copper
Conductor Stranding65/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote per FT
sjeoow 12/3
SJEOOW 12/3
Amps25
Approx LBS/MFT116
AWG Size12
Cond. MaterialBare Copper
Conductor Stranding65/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote per FT
sjeoow 12/4
SJEOOW 12/4
Amps20
Approx LBS/MFT150
AWG Size12
Cond. MaterialBare Copper
Conductor Stranding65/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote per FT
sjeoow 10/2
SJEOOW 10/2
Amps30
Approx LBS/MFT155
AWG Size10
Cond. MaterialBare Copper
Conductor Stranding104/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote
sjeoow 10/3
SJEOOW 10/3
Amps30
Approx LBS/MFT200
AWG Size10
Cond. MaterialBare Copper
Conductor Stranding104/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote per FT
sjeoow 10/4
SJEOOW 10/4
Amps25
Approx LBS/MFT257
AWG Size10
Cond. MaterialBare Copper
Conductor Stranding104/30
CSA TypeSJEOOW
Insul. MaterialThermoplastic Elastomer (TPE)
Jacket MaterialThermoplastic Elastomer (TPE)
Requires Quote
sjeo 12/3
SJEO 12/3
Approx LBS/MFT139
AWG Size12
Cond. MaterialAnnealed Bare Copper
Insul. MaterialThermoplastic Elastomer
Jacket MaterialThermoplastic Elastomer
Max. Temp105C
No. of Cond.3
No. of Strands65
Starting at 1.40 per FT In Stock

SJEOOW Service Cord Specifications

SJEOOW Construction:

  • Conductors: Bare, annealed copper per ASTM B-174 Class K stranding
  • Insulation: Color coded, Oil resistant Thermoplastic Elastomer (TPE)
    • Color Code Chart for 2 to 5 Conductors
      No of Cond.Color
      2Black, White
      3Black, White, Green*
      4Black, White, Red, Green*
      5Black, White, Red, Orange, Green*
      *Green Conductor is for Grounding Purposes only
  • Jacket: Water, sunlight and oil resistant, flame-retardant Thermoplastic Elastomer (TPE); Color: Black or Yellow

SJEOOW Ratings and Approvals:

  • Temperature Range: -50°C to +105°C
  • Voltage Rating: 300 Volts
  • UL Standard 62 for Flexible Cords
  • CSA Standard 22.2 No. 49 for Flexible Cords
  • MSHA flame resistance for mining applications
  • NEC Article 400
  • RoHS Compliant

SJEOOW Applications:

  • Portable power, both indoor and outdoor use
  • Industrial machinery and compressors
  • Heavy duty motors and industrial control systems
