STO & STOW

Our STO and STOW cables are ideal for extra-hard usage with heavy tools, equipment, portable lights, and power extensions. These cables feature an oil-resistant PVC jacket and are also resistant to oils, acids, alkalies, ozone, water, and weather. These cables have a temperature range of 40°C to 60°C and a voltage rating of 600V.

19 items

sto 14/4
STO-14/4
Amps15
Approx LBS/MFT184.00
AWG Size14
Conductor Stranding41/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 12/2
STO-12/2
Amps25
Approx LBS/MFT165.00
AWG Size12
Conductor Stranding65/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 12/3
STO-12/3
Amps25
Approx LBS/MFT208.00
AWG Size12
Conductor Stranding65/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 12/4
STO-12/4
Amps20
Approx LBS/MFT254.00
AWG Size12
Conductor Stranding65/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 10/2
STO-10/2
Amps30
Approx LBS/MFT195.00
AWG Size10
Conductor Stranding104/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 10/3
STO-10/3
Amps30
Approx LBS/MFT262.00
AWG Size10
Conductor Stranding104/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 10/4
STO-10/4
Amps25
Approx LBS/MFT323.00
AWG Size10
Conductor Stranding104/30
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only
sto 8/3
STO-8-3
Amps40
Approx LBS/MFT425.00
AWG Size8
Conductor Stranding65/.0159
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
Quote Only

STO and STOW Service Cord Specifications

STO/STOW Cable Construction:

  • Conductor: 18 through 6 AWG fully annealed stranded bare copper. Flexible, bunch-stranded per UL-62.
  • STO Cable / STOW Cable Insulation: Premium-grade, color-coded Polyvinylchloride (PVC)
    • Color Code Chart

      No. of Cond.Color Code
      2Black, White
      3Black, White, Green*
      4Black, White, Red, Green*
       *Green conductor is used for grounding purposes only.
  • Cabling: Conductors are assembled round with fillers as needed. A seperator is applied over the assembly.
  • Jacket: Polyvinylchloride (PVC) per UL-62

STO/STOW Cable Ratings:

  • Temperature Range: -40ºC to 60ºC
  • Voltage Rating: 600 volts
  • UL 62
