STO & STOW

Our STO and STOW cables are ideal for extra-hard usage with heavy tools, equipment, portable lights, and power extensions. These cables feature an oil-resistant PVC jacket and are also resistant to oils, acids, alkalies, ozone, water, and weather. These cables have a temperature range of 40°C to 60°C and a voltage rating of 600V.

19 items

STO-8-4
Amps35
Approx LBS/MFT454.00
AWG Size8
Conductor Stranding65/.0159
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
STO-6-3
Amps55
Approx LBS/MFT608.00
AWG Size6
Conductor Stranding133/.0142
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT
STO-6-4
Amps45
Approx LBS/MFT787.00
AWG Size6
Conductor Stranding133/.0142
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Min. Temp-40C
Requires Quote per FT

STO and STOW Service Cord Specifications

STO/STOW Cable Construction:

  • Conductor: 18 through 6 AWG fully annealed stranded bare copper. Flexible, bunch-stranded per UL-62.
  • STO Cable / STOW Cable Insulation: Premium-grade, color-coded Polyvinylchloride (PVC)
    • Color Code Chart

      No. of Cond. Color Code
      2 Black, White
      3 Black, White, Green*
      4 Black, White, Red, Green*
        *Green conductor is used for grounding purposes only.
  • Cabling: Conductors are assembled round with fillers as needed. A seperator is applied over the assembly.
  • Jacket: Polyvinylchloride (PVC) per UL-62

STO/STOW Cable Ratings:

  • Temperature Range: -40ºC to 60ºC
  • Voltage Rating: 600 volts
  • UL 62
