Multi-Paired

This Multi-Paired Tray cable features an overall foil shield and is sunlight and moisture resistant. This cable is often used in process control and instrumentation applications and may be installed in raceways, cable trays, and conduits. It is also approved for direct burial applications as well as aerial applications if supported by a messenger wire. This cable has a maximum temperature of +90°C in dry environments and +75°C in wet environments.

28 items

EPR/CPE 18-12P-S
Approx LBS/MFT383
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.06
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-12P-SPOS
Approx LBS/MFT438
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.062
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-1P-S
Approx LBS/MFT45
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.045
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-24P-S
Approx LBS/MFT665
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.08
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-24P-SPOS
Approx LBS/MFT796
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.082
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-2P-S
Approx LBS/MFT89
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.045
Max. Temp90C
Requires Quote
EPR/CPE 18-2P-SPOS
Approx LBS/MFT98
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.047
Max. Temp90C
Requires Quote per FT
EPR/CPE 18-36P-S
Approx LBS/MFT909
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/.0152
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialChlorinated Polyethylene (CPE)
Jacket Thickness0.08
Max. Temp90C
Requires Quote per FT

Multi-Paired VNTC Tray Cable with Overall Foil Shield Specifications

Shielded Multi-Paired Tray Cable Construction:

  • Conductor: Class B Stranded Bare Copper per ASTM B-3 and B-8
  • Insulation: PVC/Nylon
  • Shield: Aluminum/Polyester Overall Foil Shield (100% Coverage)
  • Jacket: Black PVC - sunlight and moisture resistant

Shielded Multi-Paired Tray Cable Ratings and Approvals:

  • Voltage Rating: 600 V
  • Temperature: - 30°C to 90°C Dry, 75°C Wet
  • UL 1277 Type TC-ER (3/C or more)
  • UL 66 Type TFFN
  • NEC Article 336
  • UL 1581 Vertical Tray Flame Test
  • IEEE 383 Flame Test
  • In hazardous locations as specified in NEC Article 501 (Class 1 Division 2 locations)
  • In NEC Article 336 applications
