TCGT

TCGT Wire

Our TCGT wire is rated at 300 or 600 Volts and may be used for the internal wiring of appliances and domestic, commercial, and industrial ovens. TCGT may also be used in cooking, curing, and drying equipment. TCGT is ideal for high-temperature environments found in heaters, furnaces, ovens, and kilns.

18 items

TCGT300-22
Approx LBS/MFT0.00
AWG Size22
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands7
Requires Quote per FT
TCGT600-22
Approx LBS/MFT0.00
AWG Size22
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands7
Requires Quote per FT
TCGT300-20
Approx LBS/MFT0.00
AWG Size20
Cond. MaterialNickel-Plated Copper
Conductor Stranding10/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands10
Requires Quote per FT
TCGT600-20
Approx LBS/MFT0.00
AWG Size20
Cond. MaterialNickel-Plated Copper
Conductor Stranding10/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands10
Requires Quote per FT
TCGT300-18
Approx LBS/MFT0.00
AWG Size18
Cond. MaterialNickel-Plated Copper
Conductor Stranding16/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands16
Requires Quote per FT
TCGT600-18
Approx LBS/MFT0.00
AWG Size18
Cond. MaterialNickel-Plated Copper
Conductor Stranding16/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands16
Requires Quote per FT
TCGT300-16
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialNickel-Plated Copper
Conductor Stranding26/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands26
Requires Quote per FT
TCGT600-16
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialNickel-Plated Copper
Conductor Stranding26/30
CSA TypeAWM I A/B
Insul. MaterialPTFE/Ceramic Tapes/Fiberglass Braid treated with High Temperature Saturant
Max. Temp250C
No. of Strands26
Requires Quote per FT

TCGT Wire Specifications

TCGT Cable Construction:

  • Conductor: Nickel Plated Copper
  • Insulation: PTFE Tape, Ceramic Tape, Fiberglass Braid, High-Temperature Saturant

TCGT Cable Ratings and Approvals:

  • Temperature Rating: 250°C
  • Voltage Rating: 300 volt, 600 volt
  • UL Style: UL 5331, UL 5288
  • CSA Type: Class I, Group A/B
