Sale
Amps20.0
AWG Size16
Cond. MaterialTinned Copper
Conductor Stranding259/40
Construction7 x 37/40
Mil-SpecQQW343
No. of Strands259
Nom. Circular Area (Mils)2561
Copper Rope
Copper Rope
Our Extra Flexible Copper Rope is an uninsulated wire composed of individual strands of copper. It meets the standards of ASTM-B-33 and QQ-W-343. Our braided copper rope is available in a number of AWG sizes for a variety of applications.
23 items
Sale
Amps27.9
AWG Size14
Cond. MaterialTinned Copper
Conductor Stranding168/36
Construction7 x 24/36
Mil-SpecQQW343
No. of Strands168
Nom. Circular Area (Mils)4200
Amps40
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding259/36
Construction7 x 37/36
Mil-SpecQQW343
No. of Strands259
Nom. Circular Area (Mils)6475
Amps37.8
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding665/40
Construction7 x 95/40
Mil-SpecQQW343
No. of Strands665
Nom. Circular Area (Mils)6576
Amps51.4
AWG Size10
Cond. MaterialTinned Copper
Conductor Stranding1050/40
Construction7 x 150/40
Mil-SpecQQW343
No. of Strands1050
Nom. Circular Area (Mils)10382
Sale
Amps51.2
AWG Size10
Cond. MaterialTinned Copper
Conductor Stranding413/36
Construction7 x 59/36
Mil-SpecQQW343
No. of Strands413
Nom. Circular Area (Mils)10325
Sale
Amps70.6
AWG Size8
Cond. MaterialTinned Copper
Conductor Stranding665/36
Construction7 x 95/36
Mil-SpecQQW343
No. of Strands665
Nom. Circular Area (Mils)16625
Amps96.6
AWG Size6
Cond. MaterialTinned Copper
Conductor Stranding665/34
Construction19 x 35/34
Mil-SpecQQW343
No. of Strands665
Nom. Circular Area (Mils)26434
QQ-W-343 Copper Rope Specifications
QQ-W-343 Copper Rope Conductors:
- Individual strands are soft-drawn tinned copper
- Rope lay having bunched stranded members
QQ-W-343 Copper Rope Approvals:
- QQ-W-343 Type R
- Individual strands QQ-W-343 Type S
- ASTM-B-33
