M24643/2 LSDCOP, LSTCOP

MIL-DTL-24643/2 (LSDCOP, LSTCOP)

The M24643/2 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for non-watertight, flexing service. This Mil-Spec cable features stranded bare copper conductors, Cross-Linked Polyethylene (XLPE) insulation, and an LSZH cross-linked Polyolefin (XLPO) jacket. This cable is suitable for use in shipboard applications where unusual circuit parameters require an oil-resistant and LSZH cable. It is for use only in runs within one compartment or within continuous compartments. It is not suitable to be used to penetrate a watertight deck or bulkhead. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

4 items

LSDCOP-1
Approx LBS/MFT31.00
AWG Size20
Cond. MaterialBare Copper
Conductor Stranding10/30
Insul. MaterialCross-Linked Polyethylene (XLPE)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.250
Metal TubesA
Requires Quote per FT
LSDCOP-1.5
Approx LBS/MFT0.00
AWG Size18
Cond. MaterialBare Copper
Conductor Stranding16/30
Insul. MaterialCross-Linked Polyethylene (XLPE)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.315
Metal TubesA
Requires Quote per FT
LSDCOP-2
Approx LBS/MFT0.00
AWG Size18
Cond. MaterialBare Copper
Conductor Stranding16/30
Insul. MaterialCross-Linked Polyethylene (XLPE)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.330
Metal TubesA
Requires Quote per FT
LSTCOP-2
Ampacity (50C)5
Approx LBS/MFT0.00
AWG Size18
Cond. MaterialBare Copper
Conductor Stranding16/30
Insul. MaterialCross-Linked Polyethylene (XLPE)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.345
Requires Quote per FT

MIL-DTL-24643/2 (LSDCOP, LSTCOP) Mil-Spec Shipboard Cable Specifications

M24643/2 Construction:

  • Conductor: Stranded bare copper (Class K stranding per ASTM B174)
  • Insulation: Cross-Linked Polyethylene (XLPE)
  • Jacket: Low-Smoke, Zero-Halogen (LSZH) Cross-Linked Polyolefin (XLPO) (with surface marking)

M24643/2 Ratings and Approvals:

  • Mil-Spec:
  • Navy Shipboard Spec:
    • LSDCOP (Two Conductors)
    • LSTCOP (Three Conductors)
  • Voltage Rating: 300V

M24643/2 Features and Benefits:

  • Non-watertight for mission-critical environments.
  • Thermoset system for advanced mechanical fortification.
  • LSZH system maintains circuit integrity due to minimal smoke generation, acid gas, and toxicity.
  • Oil-Resistant
