M24643/22 LS5KVTSGU, LS5KVTSGA

MIL-DTL-24643/22 (LS5KVTSGU, LS5KVTSGA)

The M24643/22 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for watertight, non-flexing service. This Mil-Spec cable features three stranded bare copper conductors, Silicone Rubber Glass Tape insulation, and an LSZH cross-linked Polyolefin (XLPO) jacket. The armored version additionally has braided aluminum armor. This cable is suitable for use in shipboard power supply, lighting, and weapon control system applications that do not exceed 5000V. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

10 items

LS5KVTSGA-100
Ampacity (50C)160
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size1/0
Cond. MaterialBare Copper
Conductor Stranding61/.0416
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Requires Quote per FT
LS5KVTSGU-100
Ampacity (50C)160
Approx LBS/MFT0.00
AWG Size1/0
Cond. MaterialBare Copper
Conductor Stranding61/.0416
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.740
Requires Quote per FT
LS5KVTSGA-150
Ampacity (50C)216
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size3/0
Cond. MaterialBare Copper
Conductor Stranding61/.0524
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Requires Quote per FT
LS5KVTSGU-150
Ampacity (50C)216
Approx LBS/MFT0.00
AWG Size3/0
Cond. MaterialBare Copper
Conductor Stranding61/.0524
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.950
Requires Quote per FT
LS5KVTSGA-250
Ampacity (50C)290
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size250
Cond. MaterialBare Copper
Conductor Stranding61/.064
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Requires Quote per FT
LS5KVTSGA-350
Ampacity (50C)360
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size350
Cond. MaterialBare Copper
Conductor Stranding91/.062
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Requires Quote per FT
LS5KVTSGA-400
Ampacity (50C)400
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size400
Cond. MaterialBare Copper
Conductor Stranding127/.057
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Requires Quote per FT
LS5KVTSGU-250
Ampacity (50C)290
Approx LBS/MFT0.00
AWG Size250
Cond. MaterialBare Copper
Conductor Stranding61/.064
Insul. MaterialSilicone Rubber Glass Tape
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)2.220
Requires Quote per FT

MIL-DTL-24643/22 (LS5KVTSGU, LS5KVTSGA) Mil-Spec Shipboard Cable Specifications

M24643/22 Construction:

  • Conductor: Stranded bare copper
    • 1/0 - 350 MCM: Class B, C & D stranding per ASTM B8
    • 400 MCM: Navy StandardConductor: Stranded bare copper
  • Insulation: Silicone Rubber Glass Tape
  • Jacket: Low-Smoke, Zero-Halogen (LSZH) Cross-Linked Polyolefin (XLPO) (with surface marking)
  • Armor (LS5KVTSGA): Aluminum Braid

M24643/22 Ratings and Approvals:

  • Mil-Spec:
  • Navy Shipboard Spec:
    • LS5KVTSGU (Unarmored)
    • LS5KVTSGA (Armored)
  • Voltage Rating: 5000V

M24643/22 Features and Benefits:

  • Watertight for mission-critical environments.
  • Meets the 1-hour fire electrical circuit integrity requirements.
  • Thermoset system for advanced mechanical fortification.
  • LSZH system maintains circuit integrity due to minimal smoke generation, acid gas, and toxicity.
