M24643/23 LSTTSU, LSTTSA

MIL-DTL-24643/23 (LSTTSU, LSTTSA)

The M24643/23 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for watertight, non-flexing service. This Mil-Spec cable features paired and stranded bare copper conductors, Extruded Silicone Rubber/Polyamide insulation, and an LSZH cross-linked Polyolefin (XLPO) jacket. The armored version additionally has braided aluminum armor. This cable is suitable for use in shipboard interconnect audio, telephone, call bell, announcing, and alarm system applications that do not exceed 1000V. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

20 items

LSTTSA-1.5
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.380
Metal TubesA
Requires Quote per FT
LSTTSA-10
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.725
Metal TubesD
Requires Quote per FT
LSTTSA-15
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.850
Metal TubesE
Requires Quote
LSTTSA-20
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.920
Metal TubesG
Requires Quote per FT
LSTTSA-3
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.500
Metal TubesB
Requires Quote per FT
LSTTSA-30
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.130
Metal TubesK
Requires Quote per FT
LSTTSA-40
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.250
Metal TubesL
Requires Quote
LSTTSA-5
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size22
Cond. MaterialBare Copper
Insul. MaterialSilicone Rubber/Polyamide
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.590
Metal TubesC
Requires Quote per FT

MIL-DTL-24643/23 (LSTTSU, LSTTSA) Mil-Spec Shipboard Cable Specifications

M24643/23 Construction:

  • Conductor: Stranded bare copper, Class K stranding per ASTM B174
  • Insulation: Extruded Silicone Rubber/Polyamide
  • Jacket: Low-Smoke, Zero-Halogen (LSZH) Cross-Linked Polyolefin (XLPO)
  • Armor (LSTTSA): Aluminum Braid

M24643/23 Ratings and Approvals:

  • Mil-Spec:
    • MIL-DTL-24643
    • MIL-I-45208A
    • MIL-STD-790
  • Navy Shipboard Spec:
    • LSTTSU (Unarmored)
    • LSTTSA (Armored)
  • Voltage Rating: 1000V

M24643/23 Features and Benefits:

  • Watertight for mission-critical environments.
  • Meets the 1-hour fire electrical circuit integrity requirements.
  • Thermoset system for advanced mechanical fortification.
  • LSZH system maintains circuit integrity due to minimal smoke generation, acid gas, and toxicity.
