M24643/24 LSTCJX, LSTCKX, LSTCTX

MIL-DTL-24643/24 (LSTCJX, LSTCKX, LSTCTX)

The M24643/24 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for watertight, non-flexing service. The conductors used in this Mil-Spec cable vary, so be sure to check individual product specs. However, all three variations feature Silicone Rubber/Glass Braid/Braid Covering insulation, a silicone rubber jacket, and aluminum braid armor. This cable is suitable for use in shipboard thermocouple and pyrometer applications. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

11 items

LSTCTX-1
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size21
Cond. MaterialCopper/Constantan (TX)
Conductor Stranding7/.0113
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.350
Requires Quote per FT
LSTCTX-12
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size21
Cond. MaterialCopper/Constantan (TX)
Conductor Stranding7/.0113
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.964
Requires Quote
LSTCTX-3
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size21
Cond. MaterialCopper/Constantan (TX)
Conductor Stranding7/.0113
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.552
Requires Quote per FT
LSTCTX-7
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size21
Cond. MaterialCopper/Constantan (TX)
Conductor Stranding7/.0113
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.731
Requires Quote per FT
LSTCJX-12
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size16
Cond. MaterialIron/Constantan (JX)
Conductor Stranding7/.0201
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)1.269
Requires Quote
LSTCJX-3
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size16
Cond. MaterialIron/Constantan (JX)
Conductor Stranding7/.0201
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.742
Requires Quote per FT
LSTCJX-7
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size16
Cond. MaterialIron/Constantan (JX)
Conductor Stranding7/.0201
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.983
Requires Quote per FT
LSTCKX-1
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size16
Cond. MaterialChromel/Alumel (KX)
Conductor Stranding7/.0201
Insul. MaterialSilicone Rubber/Glass Braid/Braid Covering
Jacket MaterialSilicone Rubber
Max O.D. (in)0.456
Requires Quote per FT

MIL-DTL-24643/24 (LSTCJX, LSTCKX, LSTCTX) Mil-Spec Shipboard Cable Specifications

M24643/24 Construction:

  • Conductor:
    • LSTCJX Cable: One iron conductor and one constantan conductor
    • LSTCKX Cable: One chromel conductor and one alumel conductor
    • LSTCTX Cable: One copper conductor and one constantan conductor
  • Insulation: Silicone Rubber/Glass Braid/Braid Covering
  • Jacket: Silicone Rubber
  • Armor: Aluminum Braid

M24643/24 Ratings and Approvals:

  • Mil-Spec: MIL-DTL-24643
  • Navy Shipboard Spec: LSTCJX, LSTCKX, and LSTCTX (All Armored)
