M24643/25 LSPI

MIL-DTL-24643/24 (LSPI)

The M24643/25 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for non-watertight, non-flexing services. This Mil-Spec cable features stranded and paired nickel-plated copper conductors, Silicone Rubber/Glass Braid insulation, a Silicone Rubber jacket, and aluminum braid armor. This cable's conductor pairs are individually shielded with a bare copper braid shield. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

3 items

LSPI-12
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size18
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/.0152
Insul. MaterialSilicone Rubber/Glass Braid
Jacket MaterialSilicone Rubber
Max O.D. (in)1.155
Requires Quote per FT
LSPI-3
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size18
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/.0152
Insul. MaterialSilicone Rubber/Glass Braid
Jacket MaterialSilicone Rubber
Max O.D. (in)0.685
Requires Quote per FT
LSPI-7
Approx LBS/MFT0.00
Armor MaterialAluminum Braid
AWG Size18
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/.0152
Insul. MaterialSilicone Rubber/Glass Braid
Jacket MaterialSilicone Rubber
Max O.D. (in)0.900
Requires Quote per FT

MIL-DTL-24643/25 (LSPI) Mil-Spec Shipboard Cable Specifications

M24643/25 Construction:

  • Conductor: Nickel-Plated Copper
  • Insulation: Silicone Rubber/Glass Braid
  • Jacket: Silicone Rubber
  • Shield: Bare Copper Braid, pairs individually shielded
  • Armor: Aluminum Braid

M24643/25 Ratings and Approvals:

  • Mil-Spec: MIL-DTL-24643
  • Navy Shipboard Spec: LSPI
