M24643/3 LSSHOF, LSDHOF, LSTHOF, LSFHOF

MIL-DTL-24643/3 (LSSHOF, LSDHOF, LSTHOF, LSFHOF)

The M24643/3 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for non-watertight, flexing service. This Mil-Spec cable features stranded bare copper conductors, EPR insulation, and an LSZH cross-linked Polyolefin (XLPO) jacket. This cable comes with varying conductor counts, so be sure to check individual product specs. All variations are suitable for use in shipboard power supply and lighting applications that do not exceed 600V. However, they may not be used to penetrate a watertight deck or bulkhead. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

37 items

LSDHOF-3
Ampacity (50C)21
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialBare Copper
Conductor Stranding26/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.425
Requires Quote per FT
LSFHOF-3
Ampacity (50C)16
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialBare Copper
Conductor Stranding26/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.480
Requires Quote per FT
LSSHOF-3
Ampacity (50C)18
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialBare Copper
Conductor Stranding65/34
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.210
Requires Quote per FT
LSTHOF-3
Ampacity (50C)17
Approx LBS/MFT0.00
AWG Size16
Cond. MaterialBare Copper
Conductor Stranding26/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.450
Starting at 2.68 per FT
In Stock
LSDHOF-4
Ampacity (50C)28
Approx LBS/MFT0.00
AWG Size14
Cond. MaterialBare Copper
Conductor Stranding41/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.460
Requires Quote per FT
LSFHOF-4
Ampacity (50C)21
Approx LBS/MFT0.00
AWG Size14
Cond. MaterialBare Copper
Conductor Stranding41/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.550
Requires Quote per FT
LSTHOF-4
Ampacity (50C)23
Approx LBS/MFT0.00
AWG Size14
Cond. MaterialBare Copper
Conductor Stranding41/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.480
Requires Quote per FT
LSDHOF-6
Ampacity (50C)37
Approx LBS/MFT0.00
AWG Size12
Cond. MaterialBare Copper
Conductor Stranding65/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.510
Requires Quote per FT

MIL-DTL-24643/3 (LSSHOF, LSDHOF, LSTHOF, LSFHOF) Mil-Spec Shipboard Cable Specifications

M24643/3 Construction:

  • Conductor: Stranded Bare Copper
  • Insulation: Ethylene Propylene Rubber (EPR)
  • Jacket: Low-Smoke, Zero-Halogen (LSZH) Cross-Linked Polyolefin (XLPO)

M24643/3 Ratings and Approvals:

  • Mil-Spec:
  • Navy Shipboard Spec:
    • LSSHOF (one conductor)
    • LSDHOF (two conductors)
    • LSTHOF (three conductors)
    • LSFHOF (four conductors)
  • Voltage Rating: 600V

M24643/3 Features and Benefits:

  • Non-watertight for mission-critical environments.
  • Thermoset system for advanced mechanical fortification.
  • LSZH system maintains circuit integrity due to minimal smoke generation, acid gas, and toxicity.
