M24643/3 LSSHOF, LSDHOF, LSTHOF, LSFHOF

MIL-DTL-24643/3 (LSSHOF, LSDHOF, LSTHOF, LSFHOF)

The M24643/3 cable is a low-smoke, zero-halogen shipboard cable. It is suitable for non-watertight, flexing service. This Mil-Spec cable features stranded bare copper conductors, EPR insulation, and an LSZH cross-linked Polyolefin (XLPO) jacket. This cable comes with varying conductor counts, so be sure to check individual product specs. All variations are suitable for use in shipboard power supply and lighting applications that do not exceed 600V. However, they may not be used to penetrate a watertight deck or bulkhead. The Mil-DTL-24643 Mil-Spec covers cables suitable for use in shipboard, communications, instrumentation, and electronic applications.

37 items

LSTHOF-23
Ampacity (50C)64
Approx LBS/MFT0.00
AWG Size7
Cond. MaterialBare Copper
Conductor Stranding210/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.900
Requires Quote per FT
LSDHOF-30
Ampacity (50C)83
Approx LBS/MFT0.00
AWG Size5
Cond. MaterialBare Copper
Conductor Stranding336/30
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.960
Requires Quote per FT
LSFHOF-42
Ampacity (50C)73
Approx LBS/MFT0.00
AWG Size4
Cond. MaterialBare Copper
Conductor Stranding209/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.380
Requires Quote per FT
LSTHOF-42
Ampacity (50C)86
Approx LBS/MFT0.00
AWG Size4
Cond. MaterialBare Copper
Conductor Stranding209/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.250
Requires Quote per FT
LSFHOF-60
Ampacity (50C)80
Approx LBS/MFT0.00
AWG Size2
Cond. MaterialBare Copper
Conductor Stranding304/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.150
Requires Quote per FT
LSSHOF-60
Ampacity (50C)153
Approx LBS/MFT0.00
AWG Size2
Cond. MaterialBare Copper
Conductor Stranding304/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)0.600
Requires Quote per FT
LSDHOF-83
Ampacity (50C)152
Approx LBS/MFT0.00
AWG Size1
Cond. MaterialBare Copper
Conductor Stranding418/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)1.450
Requires Quote per FT
LSFHOF-133
Ampacity (50C)148
Approx LBS/MFT0.00
AWG Size2/0
Cond. MaterialBare Copper
Conductor Stranding684/.014
Insul. MaterialEthylene Propylene Rubber (EPR)
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)2.000
Requires Quote per FT

MIL-DTL-24643/3 (LSSHOF, LSDHOF, LSTHOF, LSFHOF) Mil-Spec Shipboard Cable Specifications

M24643/3 Construction:

  • Conductor: Stranded Bare Copper
  • Insulation: Ethylene Propylene Rubber (EPR)
  • Jacket: Low-Smoke, Zero-Halogen (LSZH) Cross-Linked Polyolefin (XLPO)

M24643/3 Ratings and Approvals:

  • Mil-Spec:
  • Navy Shipboard Spec:
    • LSSHOF (one conductor)
    • LSDHOF (two conductors)
    • LSTHOF (three conductors)
    • LSFHOF (four conductors)
  • Voltage Rating: 600V

M24643/3 Features and Benefits:

  • Non-watertight for mission-critical environments.
  • Thermoset system for advanced mechanical fortification.
  • LSZH system maintains circuit integrity due to minimal smoke generation, acid gas, and toxicity.
