Approx LBS/MFT2
AWG Size28
Cond. MaterialSilver-Coated Copper
Conductor Stranding7/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.035
Max. Temp200C
M22759/11
M22759/11 and AS22759/11 Hook-Up Wire
Our M22759/11 wire is a highly durable Mil-Spec wire suitable for use in aircraft and aerospace applications. This wire features silver-plated copper conductors and extruded PTFE insulation. M22759/11 wire has a green or white print on the insulation for identification purposes. It also has a maximum temperature of +200°C and a voltage rating of 600V. While this cable is labeled after the Mil-W-22759 Military specification, this spec is now governed by the SAE and is officially known as AS22759/11.
11 items
Approx LBS/MFT2.5
AWG Size26
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.04, 0.040
Max. Temp200C
Approx LBS/MFT3
AWG Size24
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.045
Max. Temp200C
Approx LBS/MFT4
AWG Size22
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.051
Max. Temp200C
Approx LBS/MFT6
AWG Size20
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.06, 0.060
Max. Temp200C
Approx LBS/MFT8
AWG Size18
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/30
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.07, 0.070
Max. Temp200C
Approx LBS/MFT10
AWG Size16
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/29
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.077
Max. Temp200C
Approx LBS/MFT15
AWG Size14
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/27
Insul. MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentRC
Max O.D. (in)0.092
Max. Temp200C
This Mil-Spec Aerospace Cable is self-extinguishing and will not solder. M22759/11 is ideal for applications where reliability and high temperatures are a concern. The PTFE insulation has strong resistance to smoke emissions, vibration, and cut-through. It also offers abrasion resistance, thermal stability, and overload stability. M22759/11 cable is lightweight due to its thin wall. Allied Wire and Cable offers a variety of AS22759 cables, including standard wall and heavy wall versions. View our full catalog here or contact us with any concerns!
M22759/11 Mil-Spec Wire Specifications
M22759/11 Construction:
| Conductor | Silver Plated Copper |
| Insulation | PTFE non-stick coating with .010 nominal wall thickness |
M22759/11 Ratings and Approvals:
| Voltage Rating | 600 volts |
| Temperature Rating | -55°C — +200°C |
| SAE | AS22759/11 |
Do you still have questions about the AS22759 Specification? Learn all about it here!
