Approx LBS/MFT1810.00
AWG Size500
Cond. MaterialTinned Copper
Conductor Stranding1221/.0201
CSA TypeAWM I B 105C
Equals088713
Insul. MaterialHalogen-Free (LSZH) Thermoplastic (TPE)
Insulation Min. Avg. Wall95
TelcoFlex II
TelcoFlex II
The TelcoFlex II Central Office Power Cable features low-smoke, zero-halogen TelcoHyde insulation. It also includes either a bunched or rope bunched stranded tinned copper conductor covered with an opaque mylar tape to facilitate stripping. TelcoFlex II Cables are type RHH/LS and are to be used in accordance with the National Electrical Code. This cable has a voltage rating of 600V and has a temperature rating of 60°C in wet conditions. Temperature ratings for dry conditions are either 90°C or 105°C.
10 items
Approx LBS/MFT2680.00
AWG Size750
Cond. MaterialTinned Copper
Conductor Stranding1850/.0201
CSA TypeAWM I B 105C
Equals088714
Insul. MaterialHalogen-Free (LSZH) Thermoplastic (TPE)
Insulation Min. Avg. Wall110
TelcoFlex II Power Cable Specifications
TelcoFlex II Construction:
- Conductor: Class I (modified) bunched (8 and 6 AWG) and rope-bunched (4 AWG and larger) stranded tinned copper conductor
- Insulation: 90°C rated limited smoke, non-halogen TelcoHyde 5221, which features a limiting oxygen rating of 35%
TelcoFlex II Ratings and Approvals:
- Temperature Rating: 90°C/105°C Dry and 60°C Wet
- Voltage Rating: 600V
- UL: Central Office Power Cable; UL Standard 44 ( Type RHH/ST1 Thermoset Insulated)
- CT Rated: Sizes 1/0 and larger are UL, CT Use
- VW-1
- FT-4 Flame Test
- ASTM B-33 and B172 for Flexible Strand
- Listed for CT Use (Sizes 1/0 AWG and Larger)
- CSA: AWM / B 105°C, 600V
- Testing: Physical and electrical tests in accordance with UL Standard 44 requirements
- IEC 60674 and 60332
- RoHS and Reach Compliant
- Meets the requirements of WP93811 for Cold Flow (Creep) and Cut through
TelcoFlex is a TM of Southwire Company
