H07RN-F 14 4

H07RN-F 14-4C
0.00 / 1000 FT
H07RN-F 14-4C
  • Approx LBS/MFT: 188
  • AWG Size: 14
  • Cond. Material: Bare Copper
  • Conductor Stranding: 46/30
  • Insul. Material: Synthetic Rubber
  • Jacket Material: Synthetic Rubber
  • Max. Temp: 60C
  • Min. Temp: -25C
  • No. of Cond.: 4
  • No. of Strands: 46
  • Nom. O.D. of Cable (in): 0.512
  • Strand Size: 30
  • Voltage: 750

H07RN-F 14 4 - 14 Gauge Harmonized Cable

Our H07RN-F 14 4 14 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 14 4 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
