Additional Ratings:
MIL-I-3190E; NEMA VS-1; UL 1441; TubingAdditional Ratings
-
Approx LBS/MFT:
1.9
-
Color:
Black
-
Expanded I.D. (in):
0.049"
-
Material:
Fiberglass Braid coated with PVC
-
Max. Temp:
130C
-
Min. Temp:
-20C
-
Nom. I.D. (in):
0.04"
-
Quantity:
1000 FT
PF13018 BK001 — Alpha Fiberglass Braided Sleeving
Alpha PF13018 BK001 is a high-performance fiberglass braided sleeving solution designed for a wide range of applications. This durable tubing features a minimum temperature rating of -20°C and a maximum temperature rating of 130°C, making it suitable for both extreme cold and heat environments. With an expanded inner diameter of 0.049 inches and a nominal inner diameter of 0.04 inches, it provides excellent flexibility and adaptability for various installations. Constructed from fiberglass braid coated with PVC, this tubing is not only lightweight at approximately 1.9 lbs per 1000 feet but also meets stringent industry standards, including MIL-I-3190E, NEMA VS-1, and UL 1441. Ideal for electrical insulation, mechanical protection, and other demanding applications, Alpha PF13018 BK001 is your go-to choice for reliable performance.
