TelcoFlex IV Cable

The TelcoFlex IV cable features low-smoke, zero-halogen TelcoHyde insulation an an overall natural cotton braid soaked in a moisture-resistant, fire-retardant saturant. It also includes either a bunched or rope bunched stranded tinned copper conductor, covered with an opaque mylar tape to facilitate stripping. This cable is rated at 600V and has a temperature rating of 60°C for wet conditions and 90°C for dry conditions.

10 items

  • TELCO-500-L4
    $0.00 / 1000 FT
    • Approx LBS/MFT: 0
    • AWG Size: 500
    • Cond. Material: Tinned Copper
    View Details
  • TELCO-750-L4
    $0.00 / 1000 FT
    • Approx LBS/MFT: 0
    • AWG Size: 750
    • Cond. Material: Tinned Copper
    View Details

TelcoFlex IV Power Cable Specifications

TelcoFlex IV Construction:

  • Conductor: Class I (modified) bunched (8 and 6 AWG) and rope-bunched (4 AWG and larger) stranded tinned copper conductor
  • Insulation: Limited smoke, non-halogen TelcoHyde 5221, which features a limiting oxygen rating of 35%
  • Separator: 1 mil clear mylar tape is applied over the insulation for sizes 6 AWG and larger
  • Covering: Overall natural cotton braid. A section of completed cable has a limiting oxygen index of 35%.
  • Finish: Moisture resistant and flame retardant saturant and color finisher are applied to the braid.

TelcoFlex IV Ratings and Approvals:

  • Temperature Rating: 90°C Dry and 60°C Wet
  • Voltage Rating: 600V
  • UL: RHH/LS; Listed for CT Use (Sizes 1/0 AWG and Larger)
  • FT4-ST1 Flame Test
  • VW-1
  • ASTM B-33
  • CSA: AWM I B 105°C
  • IEC 60674 and 60332
  • RoHS and Reach Compliant
TelcoFlex is a TM of Southwire Company
